Richpeace Computerized Single Head Quilting Machine with Rotary Head

FOB Reference Price:Get Latest Price
$10,000.00 - $50,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Power(W):
according to model
Dimension(L*W*H):
3960X3930X1500
Weight:
according to model
Condition:
New
Place of Origin:
Tianjin, China
Brand Name:
RICHPEACE
Model Number:
RPQ-ST-2526-1-RS50
Max Sewing Speed:
2500
Max Sewing Thickness:
50mm
Number of Head:
Single Head
Moving Style:
Frame Moved
Voltage:
380V/50HZ 220V/60HZ
Certification:
CE
Material Size:
2750X2850
Max. Quilting Size:
2450X2550
Stitch:
Lock Stitch
Stitch Length:
2-6
Max. Quilting Density:
1500
Warranty:
13MONTHS
After-sales Service Provided:
Overseas third-party support available
Supply Ability
Supply Ability:
60 Set/Sets per Year
Packaging & Delivery
Packaging Details
Standard export package
Port
Xingang,Tianjin
Lead Time :
30days after receiving deposit.

Richpeace Computrized Single Head Quilting Machine (Rotary Head)





Product Description





RPQ-ST-2526-1-LS50









Main Features & Functions

Highest speed up to 2500rpm, normal working speed 2000-2300rpm with precise quilting.
Auto thread-cutting function which is suitable for individual jump quilting pattern, it saves labor and time on manual thread trimming work.
Automatic rotating head technology , machine will rotating head automatically after finishing quilting. It is easy to change frame for
quilting , saving time and high efficiency.
Specific custom made sewing head, with individual press foot driving, suitable for various thickness of quilting material.
Adjustable and extendable quilting frame , able to adjust the frame size according to the quilting demand .
Four Panasonic servo motors provide powerful and accurate driving force.
Automatic oil lubrication system (lubrication times can be set according to the quantity of stitch), ensure machine stable working at high speed.
Equipped with Original Japanese jumbo Koban rotary hook and bobbin.
Thread breakage detection device can stop the machine once thread is broken. Machine can continuous the quilting work at the
stopping point after re-threading.
Advanced LED lighting system gives brightness with tracking the entire quilting work, energy saving.







Richpeace pioneered the 1:1 quilting, with quilting frame fixed, sewing head and saddletree move in X/Y direction, tremendous
improved the quilting precision. Maximum quilting size up to 3.2meters.
Minimize the required installation area, solved the problem on traditional machine which occupied 2-4 times of moving frame
model, increase the utilization rate of floor plan.





Main Configuration

Taiwan linear guide rails make the machine more quietly and smoothly , the space between needle and shuttle is more stable





Stable and reliable movable knife cutting system



Stable and reliable movable knife cutting system



Panasonic servo motors driving system that provides high precision quilting.



Installed infrared facility increases safety factor(option).



German IGUS energy chains ,rigid and durable prolong life span





Optional Parts

Optional Sewing Head





Easy frame changer (Double layers)





















Company Information





Welcome to visit Richpeace's Factory



Richpeace Group Co., Limited. takes the responsibility of developing high-tech industrial standard, concentrates on reforming and advancing the traditional industry by new technology, advanced and applicable techniques under the corporate idea of  "lead by science and technology, then industry advances; make every effort, then gain the prosperous and the first class; honestly operate, then true love returns". Richpeace Group became such a high-tech enterprise with 12 companies directly under or stock-controlling. The directly under or stock-controlling companies has been nation-famous in textile and garment industry.



Through the years operation, Richpeace invested has formed the operating structure of technique's pluralism, series of products, sales networking, and international marketing, constructed 6 informationized textile and garment industrial terrace of computerized embroidery, computerized garment, computerized knitting, computerized quilting, computerized shuttle, and industry automatic control systems, developed self-owned intellectual property right of high-tech products of hundreds of products kinds, 24 series, and 6 classes. Richpeace has 24 patents in textile, garments, and embroidery industry, hundreds of software copyrights, 6 corporation's standards, and over 20 honors. And Richpeace has over 20 selling channels, 13 professional network stations. Main products exported to over 50 countries and regions such as North America, Europe, Southeast Asia, and Africa, with more than 20 international agents.



While "Peace" is the eternal subject of human beings, and "Rich" is the common goal of human beings, Richpeace Group will make joint efforts with the customers, shareholders and employees to develop a bright future side by side.
