Popular Computerized Multi Needle Chain stitch High Precision Lockstitch Mattress Quilting Machine

FOB Reference Price:Get Latest Price
$40,000.00 - $50,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Power(W):
7KW
Dimension(L*W*H):
4800 x 1600 x 2000mm
Weight:
1.5T, 1500kg
Condition:
New
Place of Origin:
Tianjin, China
Brand Name:
Richpeace
Model Number:
RPQD-RC-943/8
Max Sewing Speed:
980rpm
Max Sewing Thickness:
80mm
Number of Head:
Quilting area:94.3inch
Moving Style:
Frame Moved
Voltage:
220V, 2KW
Certification:
CE & ISO & Bureau Veritas
Max thickness:
80MM
Quilting area:
2450mm
Thread breakage detection:
Yes
Motor:
Panasonic Servo Motor
Quilting speed:
200-980RPM
Production:
60-230m/h
Power:
380V/50HZ 220V/60HZ
Warranty:
13months
After-sales Service Provided:
Overseas third-party support available
Supply Ability
Supply Ability:
600 Set/Sets per Year
Packaging & Delivery
Packaging Details
Standard export packaging
Port
Xingang,Tianjin
Lead Time :
Shipped in 30 days after payment



Product Description

Popular Computerized Multi Needle Chain stitch High Precision Lockstitch  Mattress Quilting Machine









Application

  • This machine is widely used for making high quality mattresses, quilt covers, and other household ornaments.
  • Varies patterns are able to be made by build-in computer control system
  • Maxmum quilting thickness up to 80MM.









Features

  • Bottom/upper thread breakage detection function.
  •  Auto stop when thread breakage by infrared sensor, auto needle-lifting and CNC speed adjustment.
  • Needle row and pressure pad take double rocker system instead of cam in order not to dirty the material.
  • Pneumatic thread-cutting and thread-loosening.
  • Rollers and screw mandrel take Japan Panasonic servo motors, make sure  precise quilting.
  • Special slope saddletrees design for holding thicker material smooth stitch running at high speed.

  •  Patterns made by CAD drawing system, convenient and high efficient, up to 1000 patterns can be stored in the machine.
  • Unlimited multi-span quilting and independent quilting. (180°,360°patterns are available)
  • High rigidity machine body ensure the machine quilts precisely at high speed with low noise.
  • Be qualified to quilting fabric as thick as 80mm.

  • Strong function of pattern-combining enable you to achieve the special effect, such as, pattern in pattern, pattern out of pattern.







  • Machine running state be detected in real time.

Optional

  • Automatic cutting machine







Model



Model RPED-RC-943/8RPED-RC-943/5
Needle Bar Space

76.2,76.2,152.4/

76.2,50.8, 127

76.2,76.2,152.4/

76.2,50.8, 127

Max.Quilting Thickness5050
Quilting Area24502450
Stitch Length3-83-6
Travel Distance in X-axis410430
Quilting Speed200-980RPM650-930RPM
Production60-230m/h45-180m/h
Dimension4800/1600/20004715/1200/1925
Power7kw5kw
Voltage380v 50hz / 220v 60hz380v 50hz / 220v 60hz





Company Information





Welcome visit Richpeace Company!

Richpeace Group was founded in 1993. Our main products are “4G Sewing Machine” series, Computerized Embroidery Machine series,
Computerized Quilting Machine series, Computerized Cutting Machine series, Automatic Fabric Spreading Machine series, Flat-bed Cutting
Machine series, Graphic Plotter series, Laser Cutting and Engraving Equipment series, Textile and Garment CAD software systems for different
designs and production applications. Headquartered in Hong Kong, Richpeace Group has five subsidiaries in mainland China, which are Tianjin
Richpeace Computer & Machinery Co. Ltd., and Tianjin Richpeace Trading Co. Ltd. in Tianjin, Shenzhen Richforever CAD Co. Ltd., Shenzhen
Richpeace Times Technology Co. Ltd. and Shenzhen Yinrare Computer Control Co. Ltd. in Shenzhen.
Tianjin Richpeace, as the main base of production activities, has Six branches: Sewing Equipment; Embroidery Machine; Quilting Machine; CAD
Hardware Equipment, CAM Equipment, Laser Equipment and Three workshops which are: Rack workshop, Machinery workshop, Computer and
Electronic control workshop.
Tianjin Richpeace is a “National Level High Technology Enterprise” and owner of world famous and award-winner brand “Richpeace” was
awarded numerous awards and prizes. We were granted the standard of ISO 9001 Quality Management System Certification, and our products
were granted the CE certification. We were presented the national-level “China Excellent Patent Prize” by SIPO (State Intellectual Property Office)
and Industrial Model of China Torch Plan Industrialization Project. Also, we won the prize for Famous-Brand Product of Tianjin City and were
presented the prize for High-Tech and High-Quality Products by Tianjin government. Furthermore, we were presented other famous industry
awards such as: The First Prize for Outstanding Product of CISMA 2013 by China Association of Sewing Machines, The Second Prize for
Scientific and Technical Progress by China Association of Textile Industry, and The Excellent Scientific Achievement Prize by China National
Garment Association.
Our products are sold to more than 100 countries and regions. We have branches and agencies in Hong Kong, India, Bangladesh, Vietnam, etc.
There are direct sales agencies and branches in different regions of China like Shenzhen, Beijing, Qingdao, Nanjing, Xinjiang Autonomous
Region, etc.
We hold with five core technologies of software, computerized control, automation control, machinery and laser in hands and are supported by
our Research and Development, Production and Marketing and Sales teams, Richpeace Group is the only and leading complete automation
equipment supplier who can utilize all our proprietary intellectual property rights in the world’s garment & textile-making equipment manufacturing
industry. The total investment of our enterprise is 150 million RMB; registered capital is 50 million RMB. Our operation and production plant covers
an area of 80,000 m 2 ;building gross area 45,000 m 2 . Our enterprise has 550 staff totally , with more than 80 high and mid-level technical
professionals, we hold and have been issued 211 patents, we are “Tianjin Industrial Model of Patents Holding Enterprise” and the “Tianjin
Enterprises Technology Center”. Our company aim is “Promote Traditional Industries via Utilizing Advanced Technologies”; provide world-wide
customers of garment, shoes and hats, luggage, chair cushion and home textile making industries with top-ranking and trustworthy solutions!
