Computer Flat/ Hat /T-shirt Single Head Embroidery Machine For Sale

FOB Reference Price:Get Latest Price
1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Embroidery Area:
400X450
Overall Dimensions:
1120X780X1650
Condition:
New
Place of Origin:
Tianjin, China
Brand Name:
Richpeace
Model Number:
RPED-TC-1201-400X450
Type:
Cap Embroidery Machine
Operation:
Computerized
Head Number:
Single Head
Needle Number:
12 needles
Head Interval:
400
Certification:
CE
stitch length:
0.1-12.7mm
control panel:
5 inch screen
main shaft:
servo motor
frame driving:
stepping motor
max. speed:
1000 rpm
Weight:
350KG
After-sales Service Provided:
Overseas third-party support available
Supply Ability
Supply Ability:
200 Set/Sets per Month
Packaging & Delivery
Packaging Details
VACCUM FOIL PLUS WOODEN CASE PACKING
Port
Tianjin Xingang
Lead Time :
7-20 days







 Richpeace Computerized Multi-function(Flat/Cap/T-shirt) Single Head  Embroidery Machine



                                                 Cap, Tubular, Flat Embroidery, 3 Functions in 1 Machine







Application

Computer embroidery machine with one head, can embroidery on cap, t-shirts, polo, sock, sleeve, trousers , jacket, leather clothes and football boots, shoes, bag and so on .



it also can be installed and equipped with extra device:such as coiling device, taping device, chenille device, sequin device, beads device, boring device.according to your requirements.



Machine embroidery is an embroidery process whereby a sewing machine or embroidery machine is used to create patterns on textiles. It is used commercially in product branding, corporate advertising, and uniform adornment. Hobbyists also machine embroider for personal sewing and craft projects.





MODEL:   RPED-TC-1201-400X450





Original Japan Rotary Hook          Three Main Components Design and Producted By Richpeace    10.4"touch screen

Main Features & Functions



With the normal specifications same as the Flat Embroidery Models

Multi-purpose embroidery machine: The applications of machine use are various, such as T-shirt, Sweaters, Tubular working clothes and caps as well as normal flat embroidery

Power Failure protection function: When unexpected power failure occurred, it can search for the suspension point and make a continue operation

Scale up/down: Scale the designs down to 50% or up to 200% in the increments of 1%; Rotation is by 1-degree increments

Work process back/forward is available in units of stitches, color change or designated stitch count

Adjustable presser foot: can be adjusted according to different thickness of the material



 Automatic color change

Motorized trimming system

Stepping motor hooking system

Automatic thread breakage detector

New table with rigid and good abrasion material

Optinal Rotary Hook: Japan Koban; Japan Hirose;

Italy Cerliani

X/Y linear guide rail system

Available machine color: metal  green, white

Four Wheels for moving the machine easier

200 patterns storage, up to 2, 000, 000 stitches

Able to read all popular pattern format, such as DST/ DSB

Short delivery date: 1 week



Multi-head Cap Embroidery Machine






Richpeace Computerized Embroidery Machine Main Components Parts



Main components are compatible with Tajima TMFD series!

Arm Base     Rotary Hook Base   Needle Bar Case Set

Double Cam System

Arm base with double cam driven, reduce the noise for quiet working environment, machine max. working speed can up to 1000rpm

Yarn Breakage Detection

Stable upper & lower thread breakage detection is available even at high-speed operation

Motors Driving

Fully imported servo motors for main shaft and frame driving

Motorized Cutting System

More efficient, quiet thread cutting & it improves the quality of finished products as well as productivity

Frames By Linear Guide Rail

Linear guide rail assures more accurate frame driving with low noise & more delicate embroidery

Color Change By Linear Guide Rail

Ensures accurate, fast running process & easier maintenance

Anti-Vibration Device

Reduce the machine vibration during working to improve machine performance





Popular Models

Model

Head

Needle

Embroidery Area(mm)

Mix.speed

Weight

(kg)

Power

(kw)

Input power

supply

Machine dimensions(mm)







Flat

Tubular

Cap

Flat

Cap/Tubular







L

W

H

TC1201

1

12

400X450

520X450

380x380

170x70

1000

750

340

380

1.0

single phase

220V/50Hz

1120

1360

1200

1230

1650

TC9902

2

9

360X450

280x280

170x70

1000

750

420

1.7

1680

1260

1650

TC1202

12

400X450

460

1800

1260

1650

TC904

4

9

360X450

280x280

170x70

1000

750

820

2.0

3-phase

380V/50Hz

2480

1410

1650

TC1204

12

400X450

860

2680

1410

1650

TC906

6

9

360X450

280x280

170x70

1000

750

920

2.2

3200

1410

1650

TC1206

12

400X450

960

3480

1410

1650
